2.4 meters internal height

20ft prefab container house

  • Unfold size: 5900*6420*2560mm

  • Folded size: 5900*2250*2560mm

  • Weight: 3500KG

  • Service life: 30~40 years

  • Optional Accessory: Decorative material, kitchen,Toilet, bathroom, electrical appliance, furniture, etc.

  • GET A QUOTE: info@hydhhouse.com


  • Product Details
  • Advantages
  • Specifications
  • Application
  • Packaging
  • Case

Engineered for durability and ease of use, these expandable container houses are crafted with a galvanized steel framework that promises a service life of 30-40 years. The construction includes 3mm hot galvanized steel, 18mm fiber cement boards, 1.8mm PVC flooring, and 50mm rock wool, EPS, or PU sandwich panels, ensuring robustness and insulation. Available in white, charcoal, or custom colors, these mobile prefab expandable houses can be customized to meet specific requirements.


Prefab expandable house features:

◆ Durable Construction: Robust 3mm hot galvanized steel and 50mm insulation for enduring quality.

◆ Customizable Design: Expandable prefab homes are tailored to specific needs with a choice of colors and features.

◆ Quick Installation: 20ft expandable container house is prefabricated for rapid setup within 4 hours, reducing labor costs.

◆ Expandable Space: Flexible living or working areas that can be increased as required.


Prefab expandable house applications:

◆ Residential Use: Ideal for personal living spaces, offering comfort and customization.

◆ Commercial Applications: Suitable for offices, dormitories, shops, and bars, providing a durable and adaptable environment.

◆ Emergency and Relief: Perfect for emergency rooms and disaster relief, with rapid deployment capabilities.

◆ Temporary Housing: Efficient for temporary housing needs, especially in construction and field work scenarios.

20ft prefab container house

20ft prefab container house

20ft prefab container house

20ft prefab container house

20ft prefab container house

Quality guarantee

R&D Capacity

The company has 8 years of research and development and production experience.

ODM service

Production Capacity

We have a complete R & D system, technical system, manufacturing system and operation and maintenance system.

Quality Control

Quality Control

Most of the materials used in the expandable prefab houses have passed CECNAS, BV, iso9001 and other certifications.

OEM Capacity

OEM Capacity

We provide creative design and construction services for private customization and other fields.

Trade Capacity

Trade Capacity

Our expandable modular houses are sold all over the world and we have rich experience in foreign trade.

CEertificates

CEertificates

Our 20ft prefab expandable houses have successfully passed the CE certification, and we will do better.

Product custom size
720 External standard size
5900*4830*2530mm
20FT External standard size
5900*6420*2530mm
30FT External standard size
9000*6420*2530mm
40FT External standard size
11800*6420*2510mm
2.4m height 20FT External standard size
5900*6420*2560mm
2.4m height 40FT External standard size11800*6420*2560mm
Usage
House,Office, Dormitory, Shop, Bar, Emergency Room, Disaster Relief Room
Advantages
1. Large space, Large -sized windows and door. 20ft 40ft can be choose, also supply customized according to your demand
2. Easy and fast installation. 4 hours/set, save labor cost
3. Pre-build the electricity and water plumbing, bathroom fittings
4. Waterproof wall board integrated design


Product details
Main Material
Galvanized steel structure with sandwich panel wall and doors, windows, etc.
Color
White, Charcoal or according to customer's requirement.
Steel Structure
3mm Hot galvanized steel structure with 4 corner casts and 18mm fiber cement board; 1.8mm PVC flooring; 50mm rock woll, EPS or PU
sandwich panel; Galvanized steel base plate.
Roof
3-4mm Hot galvanized steel structure with 4 corner casts and 50mm -70mm EPS or PU sandwich panel; Galvanized steel roof covering.
Columns
3mm Hot galvanized steel structure
Wall
50/75/100mm EPS/Rock woll/PU sandwich panel
Door
Made of steel/aluminum frame, Broken bridge aluminum.Dimension W1930mm*2100mm glazed with double glass in a thickness of 5/8/5mm.
Can be customized according to demand.
Window
Made of PVC/aluminum fame,Broken bridge aluminum.Dimension W1125mm*H1100mm, glazed with double glass in a thickness of 5/8/5mm.
Floor
The load-bearing floor material of the three units is 18mm thick cement sanding board, which has high flatness, moisture resistance and waterproof strength.
Connection Kits
PVC connection kits for floor, ceiling, walls.
Electricity
3C/ CE / CL / SAA Standard, with distribution box, lights, switch, sockets, etc.
Optional Accessory
A/C, office, dormitory, Toilet, kitchen, bathroom, shower, steel roof, electrical appliance for accomodation, cadding panels, decorative material, furniture, sanitary, kitchen,etc.


Product features
Water proof
99.9999%
Fireproofing
Grade A
Withstand wind
120km/h
Anti-seismic
Grade 10
Sound insulation
≥30 dB
Roof live load
1.0kn/m2
Floor live load
2.5kn/m2
Wall live load
1.0kn/m2
Service Life
30~40years



Residential

Residential

Office

Office

Hotel

Hotel

project

project

Rental housing

Rental housing

Homestay

Homestay

As a professional prefab expandable house supplier, Hongyu Dinghao Module Housing is committed to the research and development, design, production, processing, sales, transportation, installation and construction, after-sales service and a series of complete supporting services of new integrated housing and supporting products, with 8 years of research and development and production experience, and has the right to import and export foreign trade.

20Ft Expandable Prefab House





  • Prefab Expandable House Packaging

  • Prefab Expandable House Packaging

  • Prefab Expandable House Packaging

  • Prefab Expandable House Packaging

  • Prefab Expandable House Packaging

Niger case

Niger case

Russian case

Russian case

Australian case

Australian case
